1.Soldering tip and heating element is integrated togather.
2.Rapid heating only need 5 seconds, temperature reach 350℃;
3.Auto-matic sleeping system when you put the soldering iron tip into the stand.
4.Soldering iron tip can use 100,000 times to welding dos.
5.LED temperature digital display;
6.Different soldering iron tip can stafy different requirement;
7.Accurate temperature control, temperature accuracy is only ±5℃;
8.Soldering iron tip replace freely, it can change different tip easliy when it is working;
|
Model :
|
T12-11 soldering station
|
|
Temperature range :
|
0°C -400°C
|
|
Working voltage :
|
110V/220V 50Hz/60Hz
|
|
Output voltage:
|
24V
|
|
Maximum power :
|
75W
|
3 Seconds, Fast Heating
The new generation patent heating system improves 3 times of heat efficiency, temperature response speed increases 16 times, the heating performance increases 48 times than traditional soldering station. The time to heat up to 350°C takes only 3 seconds.
Technical Parameters
| MODEL |
T12-11 |
| Power |
75W |
| Voltage |
Input: 230V/50Hz; Output: 24V |
| Temperature Range |
100~400°C |
| Temperature Stability |
±2° (No load still air) |
| Soldering tip resistance to ground |
<2Ω |
| Soldering tip potential to ground |
<2mV |
| Weight |
2.65KG |
Comply with CE standard, electromagnetism compatibility and ESD protection standard
Related connectors and iron holder should connect ground cable to enable ESD protection function.
Accurate temperature control
Unique intelligence temperature control system works with powerful heating system, the temperature management becomes more accurate; the temperature tolerance is within ±5°.
No need to calibrate temperature during operation.
Auto Sleep, Prolongs Soldering Iron Life
When the soldering iron puts back to the iron holder, the soldering tip temperature will automatically reduces to 150°C; when pick up the soldering iron temperature increases to preset value rapidly. The soldering iron life extends to 5 times as well as saving energy.
![]()
Triple ESD Protection
T12-11 soldering station uses aircraft grade components, it has much better ESD safe performance than normal soldering station.
Every kind of precision components can be soldered easily.
Various Soldering Tips
