    Product Details:

    Place of Origin: Guangdong, China
    Brand Name: SMT YAMAHA FEEDER
    Model Number: FS feeder FT feeder

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 pieces
    Price: $175.00/pieces 10-199 pieces
    Packaging Details: FS feeder FT feeder packing with foam +carton
    Supply Ability: 2000 Piece/Pieces per Month FS feeder FT feeder
    Contact Now
    Detailed Product Description
    Condition: New Weight (KG): 3
    Showroom Location: None Video Outgoing-inspection: Provided
    Machinery Test Report: Not Available Marketing Type: Ordinary Product
    Warranty Of Core Components: 1 Year Core Components: YAMAHA FEEDER FS 8*2MM
    Warranty: 1 Year Item: FS Feeder FT Feeder
    Applicable Models:: YAMAHA YV Series YG Series Alternative Feeder:: FV CL FT FS Feeder
    Whatsapp: +8613424013606 Wechat: JoyLY0322
    Skype: Sensenhenhao Web: Https://www.smtproductionline.com
    MOQ: 10PCS Lead Time: 3-7days
    Package: Carton Port: Shenzhne

    OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine

    whatsapp:+8613424013606, skype:sensenhenhao,wechat:JoyLY0322

     OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine

    We are smt solution provider more than 16yeras.

    All smt machine line and parts, PCBA cleaner machine line we can support you.

     OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine

    OEM electronic feeder for Yamaha YV YG series pick and place machine

    OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine

    FS feeder FT feeder parameters

    Model: YV-08 / 12 / 16/ 24/ 32mm

    Applicable models: YAMAHA YV series YG series

    Alternative Feeder: FV CL FT FS Feeder

    Main body material: aluminum alloy

    Positioning method: double pin guide rail positioning connecting rod locking

    Electrical interface: single-pin contact interface

    Voltage: DC24V

    Current: 0.5A | 2.5A MAX.

    Communication method: Pulse

    Drive mode: electric drive

    Feeding speed: 68ms/pcs 4mm pitch

    Feeding accuracy: X axis ±0.05mm, Y axis ±0.05mm

    Feeding speed: 80000CPH

    Lamination recycling: inclined-pull coiling mechanism

    Applicable package: 8/12/16/24/32/44/56MM standard SMT package

    Applicable materials: all materials that can be packaged in standard YMH

    Refueling method: overall refueling, tape refueling

    Working temperature: temperature -20~65℃

    Working humidity: humidity 20~90%RH, no condensation

    Storage temperature: temperature -40~85℃

    Storage humidity: humidity 10~95%

    Aging test: 72 hours of continuous work without abnormality

    Operation record: complete and consistent

    Service life :>=20K hrs.MIL-HDBK-217F(25℃)

    OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine

    The stepper motor replaces the cylinder drive of the traditional feeder, and the precision copper gear replaces the mechanical link drive.

    By taking the electrical contact pin, connecting the 24V safety power supply, the shielding sensor converts the mechanical signal of the placement machine

    An electrical signal is generated to control the feeder to work.

    OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine

    Upgrade advantage: Wide range of electronic material models. 8mm is compatible with two packaging methods of paper tape, and 1mm/2mm/4mm steps can be switched with one key. One AREED 8mm electric feeder is used instead of the original three 8mm feeders.



    OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine

    Precision advantage: The drive motor runs with a smaller amplitude than the cylinder, which reduces the material deviation caused by vibration. High-precision feeding gears are matched with high-precision motors to ensure accurate feeding every time. The self-developed FEEDER calibrator can capture the X/Y coordinate value of each feeding, and calculate the CA\CP and CPK values to judge the consistency of the feeding accuracy of each FEEDER.



    OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine

    Speed advantage: feeding speed: Omron grating sensor quickly senses machine signal, self-developed control board software algorithm is more scientific and reasonable, stepper motor is equipped with acceleration gear, FEEDER feeding speed exceeds the pick-up limit of placement machine.

      Line change speed: stripping tape directly above, with self-contained film storage room; batch line change without dismantling the feeder, automatic warehouse opening reminder when the material is full, truly realizing the function of non-stop material change, and the line change efficiency can be increased by more than three times.

    OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine

    Compatibility advantage: Applicable to all YAMAHA machinery FEEDER platform machines on the market. It is convenient to install conductive brackets, without changing or destroying the original lines, which is simple, safe and effective. After the change, it does not interfere with the original mechanical feeder position, and can be used alternately at the same time.

    OEM FL feeder FS feeder FT feeder 12mm for yamaha pick and place machine
