Reflow Oven Checker WICKON X6 6 channels

Reflow Oven Checker WICKON X6 6 channels

    • Reflow Oven Checker WICKON X6 6 channels
    • Reflow Oven Checker WICKON X6 6 channels
    • Reflow Oven Checker WICKON X6 6 channels
    • Reflow Oven Checker WICKON X6 6 channels
    • Reflow Oven Checker WICKON X6 6 channels
  • Reflow Oven Checker WICKON X6 6 channels

    Product Details:

    Place of Origin: shenzhen
    Brand Name: WICKON
    Certification: CE
    Model Number: wickon x6 thermal profiler

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set thermal profiler
    Price: 3500 usd
    Packaging Details: packing with foam +carton
    Delivery Time: within 7 days after payment
    Payment Terms: TT,western union,paypal and so on
    Supply Ability: 300 sets per month
    Minimum Order Quantity: 1 set smt thermal profiler
    Usage: Industrial, reflow oven temeperature profile test
    Theory: Temperature Recorder and Analytical instruments
    Accuracy: ±0.01℃(Full scale), ±0.01℃(Full scale)
    Power: Electronic
    Sampling frequency: 0.05s~60Min
    Run Voltage: 3.7V~4.2VDC
    Contact Now
    Detailed Product Description
    Email: Joy@wickon.net Skype: Sensenhenhao
    Website: Www.wickon.net Whatsapp: +8613424013606

    SMT wave oven checker ,reflow oven thermal profiler ,wickon X6 profilling



    WICKON profile Advantages:

    1.Ensure that products meet the welding specifications

    2.Highlighting the hot furnace cooling

    3.Set oven to save time and money required

    4.So that production can be maximized

    5.Provide ISO9000 traceability process required proof





    Use these steps for profile :

    1. Set: Reset data logger and temperature measuring probe is connected to the product.

    2. through the process: the recorder placed in insulated boxes. The recording device with the product through the high-temperature furnace to record millions of temperature readings.

    3. Analysis: Insight software to understand the situation exactly the furnace is happening.



    wickon x6 thermal profile Specification:



    Project Description
    Commodity temperature curve tester
    Temperature range -200℃--1370℃
    Operating tempature 0-105℃
    The total storage capacity 4,000,000points
    Battery Without deliberately charging, automatic replenishment capacity, the real 365 without charge
    Number of Channels 6 channel
    Sampling interval 0.05s~86400s( Can be set according to the testing requirements )
    Thermocouple Types K
    Accuracy ±0.5 ℃
    Battery Type Rechargeable lithium polymer battery
    Nsulated box Weight (kg) Depending on the different specifications and different heat time
    Insulated box size (mm) Different specifications and heat time to decide
